Real-Time Handheld Analyzer Signal Shark®
Real-Time Handheld Analyzer Signal Shark®, for the Detection, Analysis, Classification and Localization of RF Signals between 8 kHz and 8 GHz. Solves complex measurement and analysis tasks reliably and quickly with the same RF performance as comparable desktop instruments.
- Frequency range 8 kHz to 8 GHz
- Extremely fast Scan Rate of up to 40 GHz/s
- 40 MHz Real-Time instantaneous bandwidth
- Powerful, live persistence spectrum to find hidden signals
- 100 % POI for signals longer than 2.8125 μs
- High Dynamic Range (HDR) Receiver
- High level accuracy
Signal Shark – Seven Senses for Signals
Sight
Signal Shark can detect lowest signals even in the presence of very strong signals. It does this by combining high sensitivity with a wide intermodulation-free dynamic range. DANL (preamp. off/on):-160 dBm / Hz / -167 dBm / Hz
Smell
The automatic DF (ADF) antenna enables SignalShark to determine the direction of a detected signal in less than a second. ADF Mobile: 200 MHz – 2.7 GHz ADF Wideband: 10 MHz – 8 GHz
Hearing
The high sensitivity to signals The high sensitivity to signals means SignalShark can locate and demodulate even signals that originate from a long way away. Two DDCs enables simultaneous measurement and demodulation.
Feeling
The lightest “touch” on a previously set trigger mask is enough for Signal Shark to record the corresponding signal. A scan rate of up to 40 GHz / s ensures fast detection even for large frequency bands.
Taste
Signal Shark analyzes and evaluates a recorded signal based on various classification criteria, helping the user to decide how relevant the signal is.
Pressure
The 40 MHz real-time measurement enables gapless, reliable detection of the slightest changes in the RF spectrum with the aid of the Spectrogram view.
Reception
The continuous real time Persistence The continuous real-time Persistence view of Signal Shark displays every change in the signal with pixel accuracy. Even hidden signals can be detected. 100 % POI signals > 3.125 μsec.
