FX180X – Optical Channel Checker
- Verify CWDM or DWDM Channels and Power
- Simultaneously test all 18 CWDM channels or 97 DWDM channels C14-62 in a single test
- DWDM ITU-T G.694.1 Channels 14-62
- CWDM ITU-T G.694.2 from 1271 to 1611 nm
- Dynamic Measurement range: ≥ 65 dB
- Supports DWDM channel grid down to 50 GHz
- Bar Graph or Table View modes
- Ideal for Remote PHY deployments
- Active Channel Pass/Fail detection
- Pass/Fail Level threshold
- A/B channel markers
- Built-in wavelength reference
- High wavelength accuracy
- Low Polarization Dependent Loss (PDL)
MPA
- Simulatneous multi-port, multi-protocol, multi-user independent testings for lab facilities.
- Compact form factor system (1U x 19 in chassis)
- Field upgradable, rack-mounted platform with up to 5 x Test Modules
- All ports can be configured independently and operated simultaneously
- One single platform for multi-protocol testing requirements which will grow as needs change and expand, allowing modules to be easily added on-site and new capabilities to be downloaded.
RXT 4111: DWDM OTDR Module
- Test DWDM Mux/Demux at ITU-T G.694.1 wavelengths
- C-band tuning (standard 89 channels at 50 GHz spacing)
- Optional extended band tuning to Channel 62 with 50 GHz spacing
- Optimized test parameters for best in class dead zones
- Event dead zone < 1m, Attenuation dead zone < 4m
- Optional V-Scout mode – Intelligent Link Mapping using intuitive icons derived from multiple test acquisitions
- Optional DWDM Light Source via OTDR port Push/Pull OTDR traces and Fiberscope images directly to Fiberizer Cloud via wired or wireless internet connection
- Built-in launch fiber to characterize OTDR connections and short fiber spans
- Universal 2.5 mm optical interfaces with inter-changeable optical adaptors (SC/FC/ST/LC)
